HSS and TCT Annular Cutter Broach Cutter Broaching Magnetic Drill Bit for Metal Sheet Faster Easier

  • High-efficiency metal cutting
  • Made from high-speed steel (HSS) and tungsten carbide tipped (TCT)
  • Exceptional durability for heavy-duty applications
  • Increases drilling speed and reduces cutting resistance
  • Available in various sizes for different metal thicknesses
  • Ideal for steel structures, construction, and pipeline processing

annular cutter drill bit
annular cutter drill bit
Product name

HSS and TCT Annular Cutter Broach Cutter Broaching Magnetic Drill Bit for Metal Sheet Faster Easier More Accurate Cutting

Material

HSS Annular Cutter: M2AL High Speed Steel

TCT Annular Cutter: Tungsten Carbide Tip + 45# Steel Body

Surface Finish

HSS Annular Cutter: Bright, TIN coating and Titanium coating are available

TCT Annular Cutter: Sand Blasted

Features

HSS Annular Cutter:

1.Made of high quality & super tough high speed steel with multi-cut geometry for ply-cutting and lower friction to reach better endurance and less breakage ;

2.Suitable for steel (such as T-brackets, large sheets), cast iron, non-ferrous and light metals;

3.Optimised cutting edge geometry for increased cutting performances and reduced cutting forces;

4.The effective cutting angles are designed for universal use in various sorts of steel;

5.Improved removal of chips thanks to U-shaped recesses. The specific geometry of the recess reduces the thermal load on the HSS core drill as the heat created in cutting is removed with the chips to a very great extent;

6.Reduction of the friction between the HSS core drill and the workpiece thanks to optimised spiral-shaped guide chamfers;

TCT Annular Cutter:

1.Tungsten carbide tipped annular cutters combine extreme hardness and durability with a wide range of possible applications in a convincing product.

2.Suitable for steel (such as T-brackets, large sheets), cast iron, non-ferrous and light metals;

3.Unique tooth geometry, cutting teeth specially grinding by CNC Machine to assure all of teeth in same level,allows for better centering and faster cutting;

4.Thin wall design enables cutters to cut faster and more efficiently by removing less material during drilling;

5.Shorter flute design allows for chips to fall freely from cutter;

About TCT annular cutter
* CARBIDE TIPPED CUTTER- Premium carbide is brazed for superior strength, durability and wear resistance.
* EFFICIENT & PRECISE- Cut holes in steel quickly, precisely and safely. It can cut holes in steel up to 7X faster than standard twist drill bits.
* EXCELLENT DESIGN- Triple-Cut geometry provide efficient cutting, fast feed rate, less vibration, smooth hole surface and long tool life.
* WIDELY USE- For smooth and easy cutting almost all types of steel, including materials that are extremely difficult to cut such as stainless steel, titanium, hardened steel and rail steel.

annular cutter drill bit
annular cutter drill bit
Operation Notice
* Wear protective equipment during operation.
* Ensure the drill and metal sheet are secured.
* Set appropriate RPM and feed rate.
* Must use with coolant during drilling.

annular cutter drill bit
