HSS Morse Taper Shank Twist Drill Bit Black 33mm 34mm 36mm 38mm Holder Drilling

  • High-Speed Steel Construction
  • Multiple Step Sizes in One Bit
  • Ideal for DIY and Professional Use

For Other Sizes, Types, Materials, Standard, Process, Packages, Please Contact us!

Products Description

Morse Taper Shank Drills

Twist drill with Morse taper shank suitable for a variety of materials and industrial applications. The tang at the end of the shank is used for ejecting the drill from the socket or sleeve. The drive and alignment is derived from the taper lock.
Procuct Name
Twist Drill
Material
HSS (Cobalt HSS-E is Available)
Size
5.0-100mm
Features
1. Reduced Shank - Suits 13mm (or larger) drill chucks.
2. 118° Standard Point - For general purpose applications.
3. Made from M2 or M35 High Speed Steel (HSS) - Offers the best combination of strength, heat & wear resistance.
4. Surface Finish - For ferrous metal drilling applications.
Application
For stainless steel, cast iron, cast steel, I-beam, aluminum alloy and other difficult-to-machine metal materials.
PRODUCT SPECIFICATIONS
HSS Morse Taper Shank Twist Drill Bit Black 33mm 34mm 36mm 38mm Holder Drilling

D
L1
L2
Morse
5.0
133
52
1
5.5
138
57
1
6.0
138
57
1
6.5
144
63
1
7.0
150
69
1
7.5
156
75
1
8.0
156
75
1
8.5
156
75
80
9.0
162
81
85
9.5
162
81
86
10.0
168
87
93
10.5
168
87
93
11.0
175
94
1
12.0
182
101
1
13.0
182
101
1
14.0
189
108
1
15.0
212
114
2
16.0
218
120
2
17.0
223
125
2
18.0
228
130
2
19.0
233
135
2
20.0
238
140
2
21.0
243
145
2
22.0
248
150
2
23.0
253
155
2
24.0
281
160
3
25.0
281
160
3
26.0
286
165
3
27.0
291
170
3
28.0
291
170
3

Details Images
HSS Morse Taper Shank Twist Drill Bit Black 33mm 34mm 36mm 38mm Holder Drilling
HSS Morse Taper Shank Twist Drill Bit Black 33mm 34mm 36mm 38mm Holder Drilling
HSS Morse Taper Shank Twist Drill Bit Black 33mm 34mm 36mm 38mm Holder Drilling
